High Precision Pillar Drilling Machine
₹2,150,000.00
Technical Specifications:
| Model | BMT-25 | BMTL-25 | BMT-25H |
|---|---|---|---|
| Drilling Capacity (mm) | 25 | 25 | 25 |
| Pillar Dia. (mm) | 90 | 90 | 90 |
| Spindle Nose | MT-3 | MT-3 | MT-3 |
| Spindle Travel (mm) | 152 | 250 | 160 |
| Spindle Center To Pillar Surface (mm) | 228 | 250 | 381 |
| No. Of Spindle Speed | 8 | 8 | 8 |
| Spindle Speed (RPM) | 96 – 2600 | 96 – 2600 | 96 – 2600 |
| Table Size (mm) | 365 x 365 | 405 x 405 | 420×420 |
| Base Size (mm) | 575×400 | 625 x 400 | 630 x 370 |
| Base To Spindle Nose (mm) | 980 | 1000 | 635 |
| Main Motor Power (HP) | 1 | 1 | 1/1.5 |
